Product Details:

• Pump Type:- Non-Metallic Air-Operated Double Diaphragm
• Maximum Air Inlet Pressure 100 psig (6.9 bar)
• Maximum Material Inlet Pressure 10 psig (.69 bar)
• Maximum Outlet Pressure 100 psig (6.9 bar)
• Air Consumption (@ 40 PSI) 1.21 cfm / gallon (approx.)
• Air Connection 1/4” NPT
• Maximum Flow Rate (flooded inlet) 51 gpm (193 lpm)
• Displacement / Cycle @ 100 PSIG 0.21 gal (0.79 lit)
• Maximum Suction Lift Dry 14 Feet, Wet 29 Feet Maximum
• Particle Size 3/16” dia (4.8 mm)
